Meet the agria 9600 - a hybrid champion
Last season Wiedenmann UK dealers launched the new look agria 9600 remote controlled banks mower for steep slopes up to 55°. Engineering and software enhancements to the rotary mulching mower have made it smarter and more effective.
Wiedenmann UK’s lead demonstrator, Andy Kerr, carries out installation and training across the country, and knows the upgraded machine well.
“The original 9600 was pretty special but by introducing smart technology, it’s been future proofed,” he said. “You can’t help but notice even more Health & Safety benefits. For contractors, local authorities and course managers this is exactly what they want. Staff risk is minimised because the operator can take a safe position up to 100 metres away.
“The 2021 version has a heavier duty design - thicker steel on the under carriage makes it sturdier and while caterpillar tracks come as standard, optional tracks with cleats can now be purchased for challenging conditions and all weathers.
“The electric motors and generator are more powerful and brushless. Stronger and greased seal bearings have been introduced while the V-belt now tensions automatically. The brushless generator requires zero maintenance so instantly it is more reliable. Brushless drive motors also mean there is no need for 1000 hours replacement. The net result is a more precise fluent feel.
“Extra smart technology has been introduced inside the control box where the electronics are protected from dust, vibration and moisture. Sensor technology intervenes in critical circumstances by alerting the operator to hidden or harmful objects such as stones and shuts down immediately. A tilt sensor will also shut down the machine if the control pad is dropped, or the operator stumbles, or if no motion is felt for three seconds. The hand-held control pad is now a LED screen with a dashboard display showing machine temperature and fuel gauge. It also sends a warning should the machine approach a critical slope or need refuelling. Safety really is at the fore front of everything,” said Andy Kerr.
The agria 9600 cuts and mulches in two directions and is effortless on a variety of applications, including fine turf, while offering an even faster way to adjust cutting height to between 50 -185 mm. With a working width of 112 cm it can cover up to 10,000 m² / hr assuming a forward speed of 10 km / hr making it very productive.
Innovative ‘electric hybrid drive’ allows the agria 9600 to be more efficient and environmentally friendly than other hydraulic concepts. Safety Extra Low Voltage (48V) electricity is generated as the petrol engine drives the mower blades and generator. Accordingly, the maintenance-free motors convert the current into powering the tracks. A replacement fuel cannister system makes refuelling safe and easy, even on difficult terrain. Two standard 10 litre cannisters can be easily removed and reconnected.
The agria 9600 is available from Agria UK operating through a network of stocking dealers across the UK and Ireland, supported by the Wiedenmann UK team of Chas Ayres, Michael James and Andy Kerr on 0141 814 3366. www.agria.de/en-gb/ @AgriaUK
